100amp MPPT Solar Controller, 100V Input, LiFePO4 (Lead Acid AGM) Lithium Battery, Maximum Input Voltage 100V, Power 1300W / 2600w (12V / 24V), Automatic Identification (k100a)
Product details
| Management number | 210742028 | Release Date | 2026/04/02 | List Price | $36.00 | Model Number | 210742028 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
This is a MPPT solar charge and discharge controller; the charging efficiency is 15%-25% higher than that of ordinary ordinary solar controllers; the MCU precisely controls the MOSFET switch to control the battery charge and discharge, effectively extending the battery life; Product parameters Rated charge current:100A 12V battery system:open circuit voltage ≤48V(Voc) maximum. PV input power:1300W 24V battery system:Open circuit voltage ≤96V(Voc) maximum.PV input power:2600W System nominal voltage :12V/24VDC Auto identifying Battery voltage range: 12V/24V Max.PV open circuit voltage:96VDC Power terminal:8AWG Dimensions:11.8 * 7.87 * 3.95 (in) Weight: 5.6lb Warm Tips: Battery must be connected first ! Never connect the solar panel array to the controller Without/Before a Battery. Never connect any inverter/ wind/ Alternator/ Charger into the charge controller! Ensure the battery voltage is enough.(>9V) Never exceed the max input power/Voltage of your controller. Package List: 1 x 100A MPPT Solar Charge Controller K100A-new 1 x Temperature sensor 1 x User Manual (English)1 x screw The solar controller is a professional product. If you have any questions before installation, please email us; we will answer as soon as possible; the professional technical team will guide the installation; worry-free after-sales guarantee，180-day worry-free warranty
- MPPT charge and discharge solar controller; 100Amp;
- Battery type: LiFePO4,lithium battery,agm battery,gel battery,lead acid battery is compatible with more battery charging;
- LCD display (automatically switch to display more parameter information);
- Prevention: Overcharge, overdischarge, overload, overheat, reverse polarity, lightning strike and other protection functions;
- 12V system: PV Voc = 18v-96v; 24V system: PV Voc = 36v-96v; The solar controller is a professional product. If you have any questions before installation, please email us; we will answer as soon as possible; the professional technical team will guide the installation; worry-free after-sales guarantee
| UPC | 783903116527 |
|---|---|
| Color | K100A |
| Voltage | 24 Volts |
| Brand Name | OOYCYOO |
| Display Type | LCD |
| Manufacturer | OOYCYOO |
| Material Type | Lead |
| Included Components | USB |
| Item Dimensions L x W x H | 7.87"L x 3.95"W x 11.8"H |
