17 Row Small Black Aluminum Engine Transmission Oil Cooler 90w Electric Fan 6AN in-Line Hose Fitting Adapter 180'F Turn-On Thermostat Temperature Switch Wiring Complete Kit
Product details
| Management number | 229610525 | Release Date | 2026/05/31 | List Price | $47.98 | Model Number | 229610525 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Fluid Cooler:Universal 17 row plate and fin aluminum heavy duty transmission cooler kit.Extend transmission life by helping prevent heat-related transmission failures.Perfect for light to medium duty truck, car or RV use and occasional towing.7/8" wide plates, 3/4" embossed turbulators which maximizes heat transfer.Dimensions: 0.75" x 7.5" x 11" with 3/8" hose barb inlets, GVW 18000 lbs.Electric Fan:Universal 12 volt high performance 6" inch small electric cooling fan.Upgraded 90 watt motor draws 7.5 amps, producing over 513 CFM.Configured as an air puller to be on the inside and pull air through.Includes mounting bracket feet and complete install fin tie strap kit.Measures 7.2" x 7" x 2.4" thickness at center and slim 1.4" at edge.Wiring Kit:Universal automotive electric fan 5-pin 40A relay switch harness kit.14AWG size wire powers 1-2 cooling fans or 12 volt auto accessories.Maximum 30 amp continuous draw with 30A in-line fuse protection.A/C override or manual toggle switch wire built directly into harness.Installation instructions, wiring diagram and components included.Hose Fitting:Universal 6AN in-line electric fan thermostat temperature switch kit.1/8" inch NPT brass thread-in probe and dual pin disconnect switch.Preset to power fan at 180'F turn-on and 165'F turn-off temperature.Anodized aluminum barbed straight push-on hose fitting adapters.Measures temp of any liquid including oil, water and coolant fluid.
- Universal 17 row plate and fin aluminum heavy duty transmission cooler kit.
- Dimensions: 0.75" x 7.5" x 11" with 3/8" hose barb inlets, GVW 18000 lbs.
- Upgraded 90 watt fan motor draws 7.5 amps, producing 513 CFM.
- 6AN in-line hose fitting electric fan thermostat temp switch kit.
- Preset to power fan at 180'F turn-on and 165'F turn-off temperature.
| ASIN | B0923JDXMJ |
|---|---|
| Model | Doesnotapply |
| Voltage | 12 Volts |
| Wattage | 90 watts |
| Brand Name | American Volt |
| Unit Count | 1.0 Count |
| Part Number | Doesnotapply |
| Manufacturer | American Volt |
| Material Type | Aluminum, Brass |
| Cooling Method | Forced Air Convection |
| Air Flow Capacity | 513 Cubic Feet Per Minute |
| Compatible Devices | Transmission Coolers |
| Power Connector Type | 2-Pin |
