DC 5-24V RS485 Modbus RTU Digital Display with External Temperature and Humidity Sensor AM2320 Module repl DS18B20 SHT10 SHT20 with Shell (External Sensor,4)
Product details
| Management number | 210264994 | Release Date | 2026/04/02 | List Price | $36.00 | Model Number | 210264994 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Product Name:DC 5-24V RS485 Modbus RTU Digital Display with External Temperature and Humidity sensor AM2320 Module repl DS18B20 SHT10 SHT20Package inlcuded:Digital display RS485 Temperature and humidity sensor+External sensor Description: Working voltage : DC 5-40V(6.5-28V recommended)Working current : Digital tube turn off is 5MA(12V), Digital tube turn on is 18MA(12V)MODBUS RTU protocol,03 Read,06 Write.Serial baud rate : 9600(default),N,8,1By modifying the RS485 address, up to 247 module s can be connected (More than 16 devices, it is recommended to use RS485 repeater)Temperature and humidity sensor is AM2320The voltage conversion module is DD4012SA,a High-efficiency and Low-heat voltage ConverterSize : Module is 59 X 30 X 18MM,Shell is 73 X 37 X 23MM,External sensor is 60 X 26 X 13MMWeight : Module is 16g,Shell is 16g,External sensor is 15gHow to use:1 Display "Eror" after power-on If "Eror" is displayed for a long time, it indicates that the sensor is not connected or is damaged2 After 5 seconds, display the temperature or humidity3 Trigger " KEY "button to switch the display temperature and humidity.(This parameter is powered down memory)4 Press and hold the "KEY" button for 3 seconds to turn off or turn on the display.(This parameter is also powered down memory)Note: If the digital tube is turn off after power-on, press and hold the "KEY" button until the digital tube is turn onTypical application:Indoor and outdoor temperature and humidity measurementTemperature and Humidity Monitoring in Computer RoomWarehouse temperature and humidity monitoringFarm temperature and humidity monitoringFor more information, please contact me
- Working voltage : DC 5-40V(6.5-28V recommended)
- Working current : Digital tube turn off is 5MA(12V), Digital tube turn on is 18MA(12V)
- By modifying the RS485 address, up to 247 module s can be connected (More than 16 devices, it is recommended to use RS485 repeater)
- The voltage conversion module is DD4012SA,a High-efficiency and Low-heat voltage Converter
- Size : Module is 59 X 30 X 18MM,Shell is 73 X 37 X 23MM,External sensor is 60 X 26 X 13MM / Weight : Module is 16g,Shell is 16g,External sensor is 15g
| Item Weight | 1.76 ounces |
|---|---|
| Manufacturer | eletechsup |
| Item model number | R444A01_A |
