ETAP-2306 GbE Copper & Fiber Ethernet Network Tap

Dualcomm ETAP-2306 is a GbE Network Tap with multiple monitor ports which can be used with either a 10/100/1000Base-T copper link (copper mode) or a 1000Base-X fiber link (fiber mode). In the copper mode, ETAP-2306 provides four aggregation monitor ports, each of which outputs a copy of aggregated inline traffic in both directions. The copper mode of ETAP-2306 is compatible with Power-over-Ethernet (PoE), which is capable of passing PoE inline power between two copper inline ports. As such, a connected PoE powered device (e.g., a PoE IP phone) can still receive the inline power seamlessly from its PoE capable link partner such as a PoE switch. In the fiber mode, ETAP-2306 provides two aggregation monitor ports and a pair of non-aggregation monitor ports. Each non-aggregation monitor port outputs a copy of inline traffic in only one direction. Using the pair of non-aggregation monitor ports is usually preferred for high data throughput situations to avoid possible packet loss due to port oversubscription. ETAP-2306 uses the standard small form-factor pluggable (SFP) modules when ETAP-2306 operates in the fiber mode. ETAP-2306 itself does not include the SFP modules, which, however, are widely available on the market for multi-mode and single-mode fiber links. Copper SFP modules are also available for use with ETAP-2306. ETAP-2306 automatically switches between the two operation modes by detecting the presence of SFP modules. No additional user configuration is needed. ETAP-2306 can be conveniently powered by USB power from a USB host device such as a Laptop computer.

• A single Network Tap for use with either a copper or fiber gigabit Ethernet (GbE) link
• SFP interface for monitoring a fiber gigabit Ethernet link (1000Base-X)
• Both aggregation and non-aggregation monitoring ports
• PoE pass-through. Compatible with Power over Ethernet (PoE)
• Capable of being powered from a computer's USB port with built-in inrush current limiting circuit to prevent the computer from possible damages or disturbances by transitional high current flow
