MECCANIXITY 8 Set 2 Pin 5mm 0.2 Inch Pitch PCB Mount Screw Terminal Block Connector Male Female, Green
Product details
| Management number | 229750630 | Release Date | 2026/05/31 | List Price | $3.20 | Model Number | 229750630 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- Terminal blocks are commonly used in systems such as industrial equipment, consumer electronics, automotive applications, including most electronic products, communication equipment, instrumentation, computers, automatic control systems, home appliances and alarm equipment, IC sockets, DIY PCB general boards, power modules, and LCD modules.
- This green PCB mount screw terminal (Model: 2EDGRK-5mm) features 2 pins with 5mm/0.2 inch spacing. Constructed with tinned copper conductors, it accepts 24-12AWG wire and is rated for 300V/20A. Dimensions are: Male - 19 x 12 x 15mm(0.75 x 0.47 x 0.59inch), Female - 17 x 10 x 15mm(0.67 x 0.39 x 0.59inch). The package includes 8 sets of these terminal block connectors.
- PCB mount screws are made of good PA66 plastic with V0 flame retardant grade, which is resistant to high temperatures, firmly fixed, and has better shockproof design, ensuring long-term tight connection and safe and reliable,excellent workmanship, stable performance,. This type of connector adopts a plug design, which is easy to install and remove, and can flexibly disconnect or replace wires or components without desoldering.
- 1. Loosen the screws to lower the lifting frame.2. Connect the wires,tighten the screws to lock the wires so they don’t fall off. 3. After both sides are connected, plug them in and they are done.
- Please pay attention to the product size before purchasing
| ASIN | B0FGJ9ZNGD |
|---|---|
| Gauge | 2.0 |
| Model | 2EDGRK-5mm |
| Pitch | 5 Millimeters |
| Brand Name | MECCANIXITY |
| Unit Count | 8.0 Count |
| Part Number | mea250516ee002609 |
| Manufacturer | MECCANIXITY |
| Mounting Type | PCB Mount |
| Connector Type | Quick Connect |
| Current Rating | 20 Amps |
| Number Of Poles | 2 |
| Specification Met | CE |
| Included Components | 1 |
