SMARTGEN HGM420N Automatic Start Generator Controller (AMF)

HGM400N series genset controllers integrate digitization, intelligentization and network technology which are used for genset automation and monitor control system of single unit to achieve automatic start/stop, data measurement, alarm protection and “three remote” (remote control, remote measuring and remote communication; SG485 module must be fitted). It fit with LCD display, optional languages interface (Chinese, English, Spanish, Turkish, Russian and French), and it is reliable and easy to use. HGM400N series genset controllers adopt micro-processor technology with precision parameters measuring, fixed value adjustment, time setting and set value adjusting and etc. All parameters can be configured from front panel or through USB interface by using PC. It can be widely used in all types of automatic genset control system with compact structure, advanced circuits, simple connections and high reliability. PERFORMANCE AND CHARACTERISTICS:HGM400N series controller has two types:HGM410N: ASM (Automatic Start Module)，it controls generator to start/stop by remote signal;HGM420N: AMF (Auto Mains Failure), updates based on HGM410N, moreover, has mains electric quantity monitoring and mains/generator automatic transfer control function, especially for automatic system composed by generator and mains.1. 132x64 LCD with backlight, selectable language interface (Chinese, English, Spanish, Turkish, Russian and French), push-button operation;2. Improved LCD wear-resistance and scratch resistance due to hard screen acrylic;3. Silicon panel and pushbuttons for better operation in high/low temperature environment;4. Suitable for 3-phase 4-wire, 3-phase 3-wire, single phase 2-wire, and 2-phase 3-wire systems with voltage 120/240V and frequency 50/60Hz;5. Collects and shows 3-phase voltage, current, power parameter and frequency of generator or mains.6. For Mains, controller has over voltage, under voltage and loss of phase detection functions; For generator, controller has ov

• Low cost AMF controller designed to start/stop a generator automatically
• Suitable for 1-3 phase gasoline and diesel gensets
• Designed for front panel mounting
• Survives cranking dropouts
• Generator protection, built-in alarms and warnings
