WF28 10 pin Industrial Electrical Power Cable Connector, 10 pins Waterproof Connector IP67, Welded Male Female Aviation Bulkhead Waterproof Connector(10PIN, 2SET)
Product details
| Management number | 226808454 | Release Date | 2026/05/09 | List Price | $101.51 | Model Number | 226808454 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Product name: WF28 10pin heavy industrial metal power connector Contact: φ2.5mm*10(Gold plated copper) Rated current: 25A Working voltage: 500V Test voltage: 1500V Contact resistance: 1mΩ Insulation resistance: 2000mΩ Wire: <2.5mm = AWG12-16 Cable: 10-14mm IP rating: Plug: IP20, socket: IP67 Mating cycle: 500times Temperature range: -25~+65°C Shell material: zinc alloy Pin number availalble:5/7/10/12/16/17/20/24/26 pin Connector whole size: 4.1*1.3inch / 104*33.8mm
- WF28 10pin high voltage heavy industrial power connector, φ28mm panel cut
- Contact: φ2.5mm*10(Gold plated copper), 25A / 500V, Contact resistance: 1 Milliohm
- Wire: <2.5MM= AWG12-16, Cable: 10-14mm, whole size: 4.1*1.3inch / 104*33.8mm
- Pin number available: 5/7/10/12/16/17/20/24/26pin, Plug: IP20, socket: IP67
- Professional and trusted power connector wholesale and retail supplier.
| ASIN | B07B9SXFT8 |
|---|---|
| Item Weight | 12 ounces |
| Manufacturer | HL-010XT |
| Package Dimensions | 6.93 x 5.24 x 1.97 inches |
| Is Discontinued By Manufacturer | No |
